5SGA30J2501 Trigger Board Design With Cooling And Protection Systems

Product details

Drive design: Special trigger board or optical fiber isolation drive is required to ensure anti-interference capability. The gate drive current must meet requirements to avoid accidental triggering or damage. Cooling system: Efficient heat sinks (such as water cooling plates or heat pipes) must be designed to control the junction temperature within a safe range. Thermal design with reference to the thermal resistance parameter (Rth) provided by ABB. Protection circuit: Configure overvoltage protection (such as RC absorption circuit) and fast fuses. Add temperature monitoring and alarm system to prevent overheating damage.
