Automatic Pallet Stretch Film Winding Machine
Shenzhen Xuanyu Technology Co., Ltd.
Product details
Manufacture and sell pallet series automatic winding machines. 1. The winding equipment uses LLDPE stretch film as packaging material to cover the entire pallet cargo, Packaging equipment for packaging operations; 2. Using pallet series winding machines can reduce packaging costs, facilitate storage and transportation, and be easy to adjust. Recycling of packaging materials; reducing environmental pollution; 3. This packaging method is widely used in railways, highways, civil aviation, and glass manufacturing. , paper industry, chemical industry, machinery manufacturing, food and other industries, especially in export trade container cargo has been widely used in transportation.
Specification
Minimum applicable specifications
L500 *W500* H500mm
Material
LLDPE stretch film
Width
500mm
Thickness
0.17-0.25 mm
Coil inner core diameter (I.D)
76 mm (3 inches)
The outer diameter of the film coil (O.D)
less than 260 mm
Column height
2400mm (can be increased)
Packaging height
2000mm (can be increased);
Power
1.5KW
The weight of the whole machine
600Kg
Rotary table height
85 mm
Working speed
2-4 M/min
Rotary table speed
0-12 rpm/min;
Port of shipping
China
Shenzhen Port
